DNF Series Energy Saving & Air Velocity Controllable Natural/Forced Convection Ovens
Manufacturer: Yamato Scientific America
The Yamato DNF Series Energy Saving Oven with Variable Flow Rates offers both natural and forced convection in one unit. This eco-oven offers an improved air velocity control system, adjustable damper, and a program featured to reduce power consumption significantly.
Description
In Stock!
Lead Times May Vary
The Yamato DNF Series Ovens are high performance, energy-saving, programmable constant temperature, forced convection ovens with air velocity control and exhaust dampers.
Performance & Functions:
- Eco-oven with improved air velocity control system and adjustable damper
- Program featured to reduce power consumption significantly
- Superior heat tightness and insulation of chamber
- Excellent dust tightness, dust can hardly enter the chamber
- Air velocity changeable in 10 stages using digital setting of controller
- Standard with 99 step program operation with repeat operation, auto start, auto stop and quick auto stop functions
- Adjustable damper position at chamber front to optimize operation
- Fluorescent display, interactive input method, calibration off-set function
Please Note: All 220V Models are not equipped with a power plug (with the exception of DNF-301-220V). The 220V models include a Rounded Terminal for M4. For more information, please refer to our downloads tab.
| SKU | Controller | Power Requirement | Material |
|---|---|---|---|
| DNF-301-115V | Model V Type | 115 V/7.5 A With Plug | Stainless Steel, Cold Rolled Steel Plate |
| DNF-301-220V | Model V Type | 220 V With External Transformer Instead of Plug | Stainless Steel, Cold Rolled Steel Plate |
| DNF-401 | Model V Type | 115 V/11 A With Plug | Stainless Steel, Cold Rolled Steel Plate |
| DNF-411 | Model V Type | 220 V/8 A No Plug, Round Terminal | Stainless Steel, Cold Rolled Steel Plate |
| DNF-601 | Model V Type | 115 V/15 A With Plug | Stainless Steel, Cold Rolled Steel Plate |
| DNF-611 | Model V Type | 220 V/8 A No Plug, Round Terminal | Stainless Steel, Cold Rolled Steel Plate |
| DNF-811 | Model V Type | 220 V/15.5 A No Plug, Round Terminal | Stainless Steel, Cold Rolled Steel Plate |
| DNF-911 | Model V Type | 220 V/18.5 A No Plug, Round Terminal | Stainless Steel, Cold Rolled Steel Plate |
|
DNF Series Specs Sheet | Download |
|
|
Yamato Scientific Electrical Plug (NEMA) Information Sheet | Download |
|
|
Yamato Scientific How to Install 220V Plug | Download |
| SKU | Includes | Width | Depth | Height |
|---|---|---|---|---|
| DNF-301-115V | 430 mm | 495 mm | 740 mm | |
| DNF-301-220V | 430 mm | 645 mm | 740 mm | |
| DNF-401 | 580 mm | 645 mm | 890 mm | |
| DNF-411 | 580 mm | 695 mm | 890 mm | |
| DNF-601 | 730 mm | 695 mm | 940 mm | |
| DNF-611 | 730 mm | 695 mm | 940 mm | |
| DNF-811 | 730 mm | 695 mm | 1685 mm | |
| DNF-911 | 1220 mm | 695 mm | 1685 mm |
The Yamato DNF Series Energy Saving Oven with Variable Flow Rates offers both natural and forced convection in one unit. This eco-oven offers an improved air velocity control system, adjustable damper, and a program featured to reduce power consumption significantly.
Starting at $6,770.00
