ThermoChill™ I Recirculating Chillers
Manufacturer: Thermo Fisher
The Thermo Scientific™ ThermoChill™ I series provides a compact yet powerful solution for laboratories requiring consistent refrigerated recirculation. Engineered to minimize downtime, these chillers feature an innovative design with reduced internal plumbing and an integrated full-flow fluid strainer that protects the pump and your application from debris. With a cooling capacity of up to 700W (2391 BTU), the ThermoChill I is ideal for removing heat from rotary evaporators, analytical instrumentation, or small industrial processes. The unit is designed for ease of use, featuring an accessible fill port and a front-mounted pressure gauge for real-time system monitoring.
Description
Choose the voltage and communication options (RS232) that match your laboratory infrastructure.
Features:
- Simplified Maintenance: The removable full-flow strainer can be cleaned without draining the system, ensuring the recirculating fluid remains free of particulates that could cause pump wear.
- User-Friendly Interface: The digital controller features clear indicator lights that illuminate during setpoint adjustments or when safety alarms are triggered.
- Space-Saving Design: Its compact footprint allows it to fit under standard lab benches, while the locking casters make it easy to move between stations as needed.
- Remote Integration: Optional RS232 or RS485 digital communications allow for automated data logging and remote setpoint control via a PC.
Operational Safety & Maintenance:
- Fluid Selection: Always use a manufacturer-approved heat transfer fluid. For operation below 8°C, a water/glycol mix is required to prevent internal freezing and evaporator damage.
- Airflow: Maintain at least 12–18 inches of clearance around the condenser vents to ensure maximum cooling efficiency and prevent the compressor from overheating.
- Pressure Monitoring: Regularly check the front-panel pressure gauge. A sudden drop in pressure may indicate a clogged strainer or a leak in your external plumbing.
| SKU | Flow Rate | Temperature Range | Type | Dimensions | Certification | Refrigerant |
|---|---|---|---|---|---|---|
| 196214010000 | 7.6 L/min | Low: -10°C to 30°C | MDC1 (Mag Drive Centrifugal Pump) | 23.8 in x 14.0 in x 23.0 in | CE, UL | R134A |
| 196214120000 | 7.6 L/min | Low: -10°C to 30°C | MDC1 (Mag Drive Centrifugal Pump) | 23.8 in x 14.0 in x 23.0 in | CE, UL | R134A |
| 196221010000 | 4.5 L/min | Low: -10°C to 30°C | PD1 (Positive Displacement Pump) | 23.8 in x 14.0 in x 23.0 in | CE, UL | R134A |
| 196224010000 | 7.6 L/min | Low: -10°C to 30°C | MDC1 (Mag Drive Centrifugal Pump) | 23.8 in x 14.0 in x 23.0 in | CE, UL | R134A |
|
ThermoChill™ Series Recirculating Chiller Product Specifications | Download |
|
ThermoChill™ Series Recirculating Chiller Product Manual | Download |
-
