Advanced Digital Refrigerated/Heated Circulating Baths
Manufacturer: Polyscience
Starting at from $5,426.00 Sale $4,883.40
Select a product below and add it to your cart to request a quote.
Advanced Digital Refrigerated/Heated Circulating Baths
Description
Advanced Programmable Temperature Controller Features
- • Optimized
The Advanced Digital Temperature Controller displays and controls bath temperatures with ±0.01°C precision and stability. Plus you can further optimize performance through a variety of control settings including pump speed, specific heat value, calibration offset, and internal or external temperature control. - • Communicative
Bi-directional RS232, addressable RS485, and Ethernet communications provide fast and versatile remote control and data logging. USB-A and USB-B enable you to log data directly to a flash drive or computer. - • Friendly
On-screen prompts and 4 languages (English, Spanish, French, and German) take the guesswork out of setup and operation. Adjusting the temperature set-point, pump speed, or other operational settings is simple, straightforward, and intuitive. In addition, the Advanced Digital Temperature Controller features a message bar that assists in making changes and provides alerts and safety information. - • Safe
The Advanced Digital Temperature Controller delivers exceptional safety for a wide variety of laboratory applications. Standard safety features include redundant over-temperature protection, low-liquid level float switch, user-settable over-temperature safety and high and low temperature limits.
Specifications | Advanced Digital Temperature Controller |
Maximum Temperature | 200°C |
---|---|
Temperature Stability | ±0.01°C |
Swivel 180™ Rotating Controller | Yes |
Pump | Variable-Speed |
Max. Pressure Flow Rate @ 60 Hz | 20.1 LPM |
Max. Suction Flow Rate @ 60 Hz | 14.7 LPM |
Closed-Loop Operation | Yes |
Open-Loop Operation | Yes |
Fluid Optimization / Specific Heat Tuning |
Yes |
Temperature Calibration Capability | 1-point |
External Temperature Control Capability (Pt100) |
Yes |
WhisperCool™ Environment Control System |
Yes |
Inert Gas Reservoir Purge | Yes |
Display Type & Size |
LCD Display with Touchpad Control 3.75 inches / 9.5 cm |
Enhanced Data Display Capability | Message Bar |
Multi-Language Menus or Prompts | 4 languages |
Displays Temperature Trend | No |
Time/Temperature Programs & Steps | No |
Date & Time with Calendar Start/Stop | No |
Timer | Yes |
On-Screen Help or Prompts | Yes |
RS232/RS485 Serial Output | Yes |
USB A and USB B | Yes |
Ethernet | Yes |
DeviceNet™/Canbus, Modbus®, Profibus® (optional) |
No |
Software Support for LabView™ Included | No |
Remote On/Off Capability | No |
Safety Class (DIN 12876-1) | III |
Over-Temperature Protection | Yes |
Failsafe Heater Control | Yes |
High and Low Temperature Limits/Alarms | Yes |
Low-Liquid-Level Safety | Yes |
Alarm and Fault Indicators | Message |
Warranty | Two years |
Specifications | 7-Liter Low-Profile |
7-Liter | 15-Liter | 20-Liter | 28-Liter | 45-Liter | ||
Temperature Range |
-20° to +200°C | -20° to +200°C | -40° to +200°C | -30° to +200°C | -40° to +200°C | -30° to +200°C | -30° to +200°C | -25° to +135°C |
---|---|---|---|---|---|---|---|---|
Part Number | AD7LR-20-A11B | AD07R-20-A11B | AD07R-40-A11B | AD15R-30-A11B | AD15R-40-A11B | AD20R-30-A11B | AD28R-30-A11B | AD45R-20-A13D |
Cooling Capacity @ 20°C |
200 W | 505 W | 915 W | 1000 W | 915 W | 1400 W | ||
Heater | 1100 W (60 Hz) | 2200 W (50/60 Hz) | ||||||
Electrical | 120 VAC, 60 Hz | 208-240 VAC, 50/60 Hz |
SKU | Depth | Width | Length |
---|---|---|---|
AD7LR-20-A11B | 16.2 in | 16.2 in | 23.2 in |
AD07R-20-A11B | 24.3 in | 8.7 in | 21.3 in |
AD07R-40-A11B | 24.3 in | 8.7 in | 21.3 in |
AD15R-30-A11B | 26.9 in | 14.5 in | 22.4 in |
AD15R-40-A11B | 26.9 in | 14.5 in | 22.4 in |
AD20R-30-A11B | 26.9 in | 16.6 in | 24 in |
AD28R-30-A11B | 26.9 in | 18 in | 26.5 in |
AD45R-20-A13D | 42.1 in | 22.4 in | 35.8 in |
