White Diamond Series Flammable Storage Freezers
Manufacturer: Corepoint Scientific
The Corepoint Scientific White Diamond Series Flammable Storage Freezers, available in 20 cu ft. and 30 cu ft. capacity, feature a microprocessor temperature controller with an adjustable display in Celsius or Fahrenheit. These freezers have visual and audible high and low-temperature alarms with remote contacts. The NEMA 5-15 plugs conform to UL471 requirements and come with a three-year parts and labor warranty.
Description
In Stock!
Lead Times May Vary
Features:
- Microprocessor temperature controller
- Adjustable temperature display in Celsius or Fahrenheit
- Audible and visual high/low temperature alarms
- Remote alarm contacts
- Keyed door lock
- Magnetic door gasket for positive seal
- Environmentally friendly refrigerant
- High density urethane foam cabinet and door insulation
- White textured cabinet and door
- Leveling legs
- Three-year parts and labor warranty
FF201WWW/0MHC Features:
- Standard digital temperature display
- Rear wall 3/4 inch probe acess port
- Two Probes, one in air and one in sample bottle
FF201WWW/0MHC Certifications:
- ETL and C-ETL listed and certified to UL471 standard
- Energy Star Certified
- Units meet NFPA guidelines 45 and 30
FF301WWW/0MTS Features:
- Touch Screen Digital Temperature Display with user friendly interface
- Alarm Module with battery back-up to support temperature monitoring and alarms
- Password-protected control panel
- Sample simulated digital temperature display with .1° resolution
- Resettable 1-point min/max history
- Digital 24-hour temperature chart
- Temperature data logging with USB port for data transfer and software updates
- Real-time operational display clock
- 4-20mA output
- Electronic QR Code to access Owner’s Manual & technical support contact information
- Adjustable alarm volume and remote alarm contacts
- Sensor error, power failure, door ajar, and low battery alarms
- Operation indicator
- Stainless steel door handle
- 3/8 inch probe access port
FF301WWW/0MTS Certifications:
- UL/C-UL listed
- Units meet NFPA and OSHA guidelines 45 and 70
- Periodic defrosting is required to prevent severe ice build-up.
- These units are NOT designed for use in environments where volatile/explosive conditions could potentially exist.
| SKU | Door Type | Operating Temperature Range | Warranty | Certification | Refrigerant | Hinge |
|---|---|---|---|---|---|---|
| FF201WWW/0MHC | Solid Swing Door | -15°C to -25°C | 3 Year | ETL, C-ETL Listed | R290 | Right |
| FF301WWW/0MTS | Solid Swing Door | -15°C to -25°C | 3 Year | UL, C-UL Listed | R404a | Right |
|
FF201WWW/0MHC Data Sheet | Download |
|
|
FF301WWW/0MTS SpecSheet | Download |
|
|
FF301WWW/0MTS Interior Cutsheet | Download |
|
|
FF301WWW/0MTS Exterior Cutsheet | Download |
| SKU | Dimensions | Electrical Information | Plug Type | Controller |
|---|---|---|---|---|
| FF201WWW/0MHC | 29.0 in x 30.75 in x 74.625 in | 115V, 60Hz, 5.5A | NEMA 5-15 (Conforms to UL471 Requirements) | Microprocessor |
| FF301WWW/0MTS | 35.25 in x 35.0 in x78.5 in | 115V, 60Hz, 6A, 1/3 HP | NEMA 5-15 (Conforms to UL471 Requirements) | Microprocessor |
The Corepoint Scientific White Diamond Series Flammable Storage Freezers, available in 20 cu ft. and 30 cu ft. capacity, feature a microprocessor temperature controller with an adjustable display in Celsius or Fahrenheit. These freezers have visual and audible high and low-temperature alarms with remote contacts. The NEMA 5-15 plugs conform to UL471 requirements and come with a three-year parts and labor warranty.
Starting at $4,952.00
Request A Quote
![White Diamond Series Flammable Storage Freezers]()
Select a product below and add it to your cart to request a quote.
