Get high accuracy and premium performance everywhere you need it with the Thermo Scientific™ Orion™ Star A321 pH Portable Meter, designed for a wide range of pH, mV, ORP and temperature testing and field applications. Evaluate samples in the most demanding locations using this waterproof meter with IP67-rated housing. Perform up to a five point pH calibration, ... Read more
Description
In Stock!
Lead Times May Vary.
About Star Com
Get high accuracy and premium performance everywhere you need it with the Thermo Scientific™ Orion™ Star A321 pH Portable Meter, designed for a wide range of pH, mV, ORP and temperature testing and field applications. Evaluate samples in the most demanding locations using this waterproof meter with IP67-rated housing. Perform up to a five point pH calibration, log up to 5000 data point sets with time / date stamp and easily transfer calibration and data logs via USB or RS232 to a printer or computer with free downloadable Orion™ Star Com software.
Features:
- • Meter includes plain language screen prompts, soft keys that update for easy selection and a multilanguage interface that supports English, Spanish, French, Italian, German and Chinese.
- • Thermo Scientific™ AUTO-READ™ locks in the stable reading on your screen, indicator alerts user when readings are stable and timed reading gathers data in specific time intervals.
- • Meter offers up to five point pH calibration with automatic recognition for USA/NIST™ and DIN buffers.
- • User can fix errors without a complete recalibration with calibration editing.
- • Nonvolatile memory holds up to 5000 datapoints with time and date stamp.
- • User can easily transfer data and keep meter software up to date with the USB and RS232 ports and complimentary data analysis software.
- • Purchase the universal power adapter (sold separately) to use AC power or use the four included AA batteries for over 800 hours of operation
- • Meter is perfectly portable, waterproof and protected to take anywhere with a IP67-rated housing.
Click here to view all specifications Close
| Specifications | STAR A321 |
| AC Adapter | Universal 50-60 Hz, 100-240 VAC power adapter (sold separately, Cat. No. 1010003) |
|---|---|
| Accuracy mV | ±0.2 mV or ±0.05% of reading whichever is greater |
| Accuracy pH | ±0.002pH |
| Accuracy Temperature | ±0.1°C |
| Alarm Output | High/low limit alarm, calibration due alarm |
| Backlight | Yes, selectable |
| Battery Life (Average) | 800 hours |
| Battery Type | Four AA (included) |
| Calibration Modes | pH with calibration editing option, relative mV (RmV), ORP and temperature |
| Calibration Points mV | 1 point relative mV (RmV) mode, 1 point ORP mode |
| Calibration Points pH | 1 to 5 |
| Certifications Compliance | CE, TUV 3-1, FCC Class A |
| Channels | 1 |
| Data Log Function Type | Automatic data logging with Auto-Read and Timed measure modes; manual data logging with Continuous measure mode |
| Data Management Details | Transfer single, range or all data points to printer or computer |
| Data Points | 5000 with date and time stamp |
| Description | Orion Star A321 pH portable meter |
| Dimensions LxWxH | 24 cm x 10 cm x 6.5 cm (9.5" x 3.9" x 2.6") |
| Display Type | Graphic LCD with backlight |
| Includes | Star A321 pH meter, 4 AA batteries, literature, computer cable and calibration test certificate |
| Inputs | BNC (pH or ORP electrode), pin-tip (reference electrode), 8 pin MiniDIN (ATC temperature probe) |
| IP Rating | IP-67 |
| Isopotential Point | 7.000pH |
| Keypad | Comprehensive with menu-specific function keys and dual purpose scroll/shortcut keys |
| Languages | English, Spanish, French, Italian, German and Chinese; Portuguese and Korean available with software update |
| Measurement Modes | pH, mV, relative mV (RmV) or ORP with temperature |
| Memory | Non-volatile memory preserves data log, calibration log and meter settings |
| Methods | 10 per channel with password protection |
| Model | Orion Star A321 pH/mV/RmV/ORP/Temperature Portable Meter |
| Outputs | USB, RS232 |
| Power Supply | 4 AA batteries (included) or universal AC adapter (sold separately) |
| Range mV | ±2000.0mV |
| Range ORP | ±2000.0mV |
| Range pH | -2.000 to 20.000pH |
| Range Relative mV | ±2000.0mV |
| Range Temperature | -5.0 to 105.0 °C, 22.0 to 221.0 °F |
| Relative Humidity Range | 5 to 85 %, non-condensing |
| Resolution mV | 0.1mV |
| Resolution pH | 0.1, 0.01, 0.001pH |
| Resolution Temperature | 0.1°C, 0.1°F |
| Stability | Selectable fast, medium, slow or Smart Stability setting; Selectable off or Automatic Smart averaging setting |
| Temperature Ambient Operating | 5 to 45°C, 41° to 113°F |
| Temperature Probe Calibration | 1 point temperature offset calibration |
| Temperature Selection | Manual or automatic with ATC temperature probe |
| Warranty | 3 year meter warranty |
| Weight | 0.5 kg, 1.2 lbs |
About Star Com
Star Com User Guide
Orion Lab Warranty Card
Get high accuracy and premium performance everywhere you need it with the Thermo Scientific™ Orion™ Star A321 pH Portable Meter, designed for a wide range of pH, mV, ORP and temperature testing and field applications. Evaluate samples in the most demanding locations using this waterproof meter with IP67-rated housing. Perform up to a five point pH calibration, ... Read more
Starting at $1,060.00
