ED Series Avantgarde Drying and Heating Chambers
Manufacturer: BINDER Inc.
The BINDER Series ED Avantgarde Line Drying and Heating Chambers with Gravity Convection are renowned for their exceptional reliability in any laboratory and application. These units ensure that the appropriate amount of heat is distributed to the corresponding specimen. This series ensures fast, uniform drying by using the drying chamber efficiently in all thermal processes.
Description
In Stock!
Lead Times May Vary
The BINDER Series ED Avantgarde Line Drying and Heating Chambers with Gravity Convection include routine drying and sterilization tasks up to 300°C. Thanks to the natural convection, all thermal processes which use this drying chamber are highly efficient. The ED series ensures fast, uniform drying.
Features:
- Temperature range: ambient temperature plus 5°C to 300°C
- High temperature accuracy thanks to APT.line™ technology
- Gravity convection
- Controller with LCD display
- Electromechanical control of the exhaust air flap
- 2 chrome-plated racks
- Units up to 115 L are stackable
- Class 2 independent temperature safety device (DIN 12880) with visual temperature alarm
- Ergonomic handle design
- USB port for recording data
Benefits:
- Best energy efficiency on the market
- Excellent temporal and spatial temperature accuracy
- USB connection for recording data
- Temperature range up to +300°C
| SKU | Temperature Range | Temperature Fluctuation | Temperature Variation |
|---|---|---|---|
| 9010-0333 | 300°C +5°C | ± 0.4 at 150°C | ± 2.3 at 150°C |
| 9010-0334 | 300°C +5°C | ± 0.4 at 150°C | ± 2.3 at 150°C |
| 9010-0335 | 300°C +5°C | ± 0.4 at 150°C | ± 1.5 at 150°C |
| 9010-0336 | 300°C +5°C | ± 0.4 at 150°C | ± 1.5 at 150°C |
| 9010-0340 | 300°C +5°C | ± 0.8 at 150°C | ± 1.8 at 150°C |
| 9010-0339 | 300°C +5°C | ± 0.8 at 150°C | ± 1.8 at 150°C |
| 9010-0341 | 300°C +5°C | ± 0.8 at 150°C | ± 3.2 at 150°C |
| SKU | # of Shelves | Dimensions | Internal Dimensions | Power Requirement |
|---|---|---|---|---|
| 9010-0333 | 2 std./4 max. | 22.06 in x 22.26 in x 24.63 in | 14.17 in x 14.96 in x 16.54 in | 230 V, 50/60 Hz |
| 9010-0334 | 2 std./4 max. | 22.06 in x 22.26 in x 24.63 in | 14.17 in x 14.96 in x 16.54 in | 120 V, 60 Hz |
| 9010-0335 | 2 std./5 max. | 27.97 in x 23.84 in x 27.78 in | 20.08 in x 16.73 in x 20.87 in | 230 V, 50/60 Hz |
| 9010-0336 | 2 std./5 max. | 27.97 in x 23.84 in x 27.78 in | 20.08 in x 16.73 in x 20.87 in | 120 V, 60 Hz |
| 9010-0340 | 2 std./8 max. | 31.91 in x 29.94 in x 37.04 in | 24.02 in x 21.65 in x 29.92 in | 240 V, 60 Hz |
| 9010-0339 | 2 std./8 max. | 31.91 in x 29.94 in x 37.04 in | 24.02 in x 21.65 in x 29.92 in | 230 V, 50/60 Hz |
| 9010-0341 | 2 std./16 max. | 45.9 in x 34.28 in x 62.6 in | 37.80 in x 23.82 in x 50.39 in | 400 V, 50/60 Hz |
The BINDER Series ED Avantgarde Line Drying and Heating Chambers with Gravity Convection are renowned for their exceptional reliability in any laboratory and application. These units ensure that the appropriate amount of heat is distributed to the corresponding specimen. This series ensures fast, uniform drying by using the drying chamber efficiently in all thermal processes.
Starting at $1,995.00
