BONT Series Natural Convection Ovens
Manufacturer: BEING Scientific
Description
The BONT Series offers unparalleled control through a 4.3-inch color touchscreen controller. Users can preset complex temperature cycles, 8 periods and 8 steps, setting temperature, time, and heating rate simultaneously. The PID Temperature Controller maintains accurate and reliable temperature control across the wide operating range of Ambient +10°C to 300°C. The inner chamber is made from corrosion-resistant mirror stainless steel with rounded corners for easy cleaning. Safety is paramount: the oven is equipped with comprehensive alarms, over-temperature protection, and an independent over-temperature limit controller, and is ETL certified with a 2-year warranty.
Features:
- Natural convection heating provides low air turbulence for gentle drying
- Temperature Range: Ambient +10°C to 300°C
- 4.3-inch color touchscreen controller with a programming function for up to 8 periods and 8 steps
- Corrosion-resistant mirror stainless steel inner chamber with round curved inner angles for easy cleaning
- PID Temperature Controller provides accurate and reliable temperature control
- Independent over-temperature limit controller for added safety
- Auto Start Feature after power loss/return
- Extended Life Silicone Rubber Gasket provides excellent sealing
- Anti-skid shelf design for easy single-hand operation
- Select models have Space-saving Stackability (BO211120U & BO211200C)
- Available in volumes from 30 L to 211 L
| SKU | Model # | Temperature Stability | Temperature Uniformity | Heating Rate | Includes | Access Port | Type | Material |
|---|---|---|---|---|---|---|---|---|
| BO211030U | BON-30T | ±0.5 | ±3.0 @ 100°C | 40 mins to 100°C | USB Data Port | 5 mm | Natural Convection | Stainless Steel |
| BO211050U | BON-50T | ±0.5 | ±3.0 @ 100°C | 40 mins to 100°C | USB Data Port | 5 mm | Natural Convection | Stainless Steel |
| BO211120U | BON-115T | ±0.5 | ±3.0 @ 100°C | 40 mins to 100°C | USB Data Port | 5 mm | Natural Convection | Stainless Steel |
| BO211200C | BON-200T | ±0.5 | ±3.0 @ 100°C | 40 mins to 100°C | USB Data Port | 5 mm | Natural Convection | Stainless Steel |
| SKU | Dimensions | Internal Dimensions | Plug Type | Power Requirement | Display | Display Resolution | Controller | # of Shelves | Shelf Capacity | Warranty | Timer Range | Certification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BO211030U | 24.0 in x 22.8 in x 20.5 in (610 mm x 580 mm x 520 mm) | 12.6 in x 12.6 in x 11.8 in (320 mm x 320 mm x 300 mm) | NEMA 5-15 | 120V, 60 Hz, 1200W | Touchscreen | 0.1 | PID | 2 Shelves | 20 Kg | 2 years | 01:00 - 99:59 | ETL |
| BO211050U | 27.1 in x 25.2 in x 18.4 in (690 mm x 640 mm x 468 mm) | 15.8 in x 14.9 in x 13.0 in (400 mm x 380 mm x 330 mm) | NEMA 5-15 | 120V, 60 Hz, 1600W | Touchscreen | 0.1 | PID | 2 Shelves | 20 Kg | 2 years | 01:00 - 99:59 | ETL |
| BO211120U | 31.9 in x 23.2 in x 29.7 in (810 mm x 755 mm x 590 mm) | 20.5 in x 19.4 in x 17.7 in (520 mm x 495 mm x 450 mm) | NEMA 5-15 | 120V, 60 Hz, 1800W | Touchscreen | 0.1 | PID | 2 Shelves | 20 Kg | 2 years | 01:00 - 99:59 | ETL |
| BO211200C | 37.0 x 25.9 x 35.8 in (940 mm x 910 mm x 658 mm) | 25.6 in x 25.6 in x 19.6 in (650 mm x 650 mm x 500 mm) | NEMA 6-15 | 240V, 50/60 Hz, 2250W | Touchscreen | 0.1 | PID | 2 Shelves | 20 Kg | 2 years | 01:00 - 99:59 | ETL |
Starting at $1,700.00
Select a product below and add it to your cart to request a quote.
